WFCO’s proven WF-8740-AD Power Center offers an industry-first, Auto-Detect technology. This new microprocessor-driven technology will recognize lithium-ion and lead-acid battery chemistries and automatically adjust the charging profile to match the battery type. An accurately charged battery gives RV owners peace of mind. Eliminating the risk of over and under-charging, the WF-8740-AD Power Center will maximize your battery life with multi-stage charging and current monitoring in both lead-acid and lithium-ion profiles. No more buttons. No more switches.

– With Auto-Detect Intelligent Battery Detection
– Selects Correct Charging Profile for Lead-Acid & Lithium-Ion Batteries
– Color: Black
– Case Material: Plastic
– Power Input: 680W
– Input Voltage: 105-130 VAC / 60 Hz
– Output Current (LA/LI): 40A / 37A
– Converter Type: 3 Stage Converter Charger / 2 Stage Converter Charger
– Voltage Output: 13.2 – 14.4 VDC / 13.6 – 14.6 VDC
– Normal Mode: 13.6 VDC
– Trickle Charge Mode (LA Only): 13.2 VDC
– Bulk Charge Mode (LA/LI): 14.4 VDC / 14.6 VDC
– AC Circuits: (1) Main with (5) Branch Circuits
– DC Circuits: (5) Branch & (1) Battery
– Outer Dimensions: 11-7/8”W x 8-1/4”H x 5-5/16”D
– Rough Opening: 10-3/8”W x 6-7/8”H x 4-5/16”D
– Weight: 5.5 lbs.
– Certifications: UL and cUL listed and FCC Class B Compliant
– Safety Features/Protections: Over Current, Over Temperature, Over Voltage, Reverse Polarity
– Specifications are Subject to Change Without Notice or Obligation
– 2 Year Limited Warranty
